VSD PM COMPRESSOR HZV SERIES

The HZV Series VSD PM Compressor combines variable speed drive (VSD) and permanent magnet (PM) motor technology to deliver superior energy efficiency and stable performance for industrial compressed air needs. Its VSD system adjusts motor speed dynamically to match air demand, reducing energy consumption by 30-50% compared to fixed-speed models, while the PM motor ensures high efficiency across all load ranges. Designed for reliability, this compressor maintains consistent pressure output and features a durable screw airend, making it ideal for manufacturing, automotive, and general industrial applications where energy savings and steady air supply are priorities.
  • VSD PM COMPRESSOR HZV SERIES

Availability:
Quantity:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button


VSD PM COMPRESSOR HZV SERIES


ModelHZV10AHZV15AHZV20AHZV30AHZV50AHZV75AHZV100AHZV120AHZV150AHZV175A
Parameter
Exhaust volunme
Exhaust pressure
m³/min/Mpa
1.2/0 .71.65/0 .72.5/0 .73.8/0 .76.8/0 .710/0 .713.4/0 .716.2/0 .721/0 .724.5/0 .7
0.98/0 .81.79/0 .82.16/0 .83.39/0 .85.96/0 .88.77/0 .811.71/0 .815.0/0 .819.8/0 .823.2/0 .8
0.95/ 1 .01.3/ 1 .02.1/ 1 .03.2/ 1 .05.6/ 1 .08.5/ 1 .011.2/ 1 .013.8/ 1 .017.4/ 1 .020.5/ 1 .0
0.8/ 1 .251.1/ 1 .251.9/ 1 .252.7/ 1 .255.0/ 1 .257.6/ 1 .2510.0/ 1 .2512.3/ 1 .2514.8/ 1 .2517.4/ 1 .25
Lubricating oil quanitity3.57.51216.545507290
Noice   dB(A)66±268±272±275±2
Driving modeCoaxial direct couplingDirect link
Power380V/50Hz
Power Supply7.511152237557590110132
Startup modeFrequency conversion star
exterior dimensionL mm900108010801300160016502454
W mm700780880980120012001500
H mm880100012001200150015001840
weight [Kg]1402052102964438341047174617501790
Pipe diameterG1G1-½G2G2-½
